W25QXX DataFlash Board

SKU:11437
Part No.:W25QXX DataFlash Board
Brand:Waveshare

$6.99
PriceQuantity
$6.592+
$6.293+
$6.094+
Description

Details

Serial DataFlash Module with W25Q128JV Onboard, SPI Interface

Overview

  • Onboard serial NOR Flash memory W25Q128JV
  • Supports Standard/Dual/Quad SPI
  • Supports STM32F7 series Quad-SPI interface, provides related cube library demo

Features

  • Capacity: 128M-bit / 16M-byte
  • Max frequency: ≤133MHz
  • Operating voltage: 2.7~3.6V
  • Operating temperature: -40°C ~ +85°C
  • Dimension: 20.6mm × 38.9mm

Dimensions

W25QXX DataFlash Board dimensions

Development Resources

Wiki : www.waveshare.com/wiki/W25QXX_DataFlash_Board

Weight: 0.007 kg

Quick Overview

  1. W25QXX DataFlash Board x1
