Network Attached Storage(NAS) All-In-One Mini-Computer for Raspberry Pi Compute Module 4, Personal Network Storage Server, Optional For CM4 Module
NAS Mini-Computer for CM4
Designed for Raspberry Pi Compute Module 4
Personal Network Storage Server
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-1.jpg)
Features at a glance
- All-in-one Mini-Computer, mainly designed for home or small home office, but not limited to the above applications
- Out of the box, no expert knowledge of networking and storage systems required
- Built-in 2x SATA slots for installing 2.5-inch Solid State Drives
- 2-inch SPI LCD screen for real-time monitoring the working status of CM4: CPU, RAM, system disk usage, network speed and temperature, etc.
- Easy to use, convenient to online access the documents, videos, and music at any time
Specifications
Processor * | Broadcom BCM2711 Quad-Core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz |
---|---|
RAM * | CM4104008: 4GB CM4102032: 2GB |
EMMC FLASH * | CM4104008: 8GB CM4102032: 32GB |
Connectivity | Dual-band (2.4GHz/5.0GHz) IEEE 802.11b/g/n/ac wireless WiFi, Bluetooth 5.0, BLE with onboard and external antenna options * |
Gigabit Ethernet RJ45 connector | |
2 x USB 2.0 ports | |
2 x SATA slots (2.5inch SATA) | |
TF card slot for Compute Module 4 Lite (without eMMC) variants | |
HDMI × 1, supports 4K 30fps output | |
Operating voltage | 5V DC |
* the CM4104008 or CM4102032 is optional. You can choose and purchase other variants of Compute Module 4 according to your needs
Built-in Dual Hard Drive Slots
Support Large Capacity HDD Storage
Support Large Capacity HDD Storage
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-3.jpg)
Comes With SPI 2inch LCD Display
For monitoring the working status of CM4 in real-time
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-5.jpg)
Rich Interfaces
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-6.jpg)
Aluminum alloy Case Design
Alloy Case For Large Area Heat Dissipation, with fan vents and nonskid feet at the bottom, better heat dissipation and more stable placement
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-7.jpg)
Precise Cut-Out With Clear Label
Each Cut-Out Is Completely Aligned With The Connector
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-9-1.jpg)
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-9-2.jpg)
Product Show
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-11.jpg)
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-13.jpg)
Dimensions
![](/img/devkit/accBoard/CM4-NAS-Double-Deck/CM4-NAS-Double-Deck-details-size.jpg)
Resources & Services
![](/img/devkit/LCD/common/res_banner.png)
* Resources for different product may vary, please check the wiki page to confirm the actually provided resources.
Quick Overview
CM4-NAS-Double-Deck-C4A
- CM4-NAS-Double-Deck with CM4104008 included (assembled) x1
- OPTIONS 5V 3A Type C power supply x1
- Screwdriver x1
CM4-NAS-Double-Deck-C4B
- CM4-NAS-Double-Deck with CM4102032 included (assembled) x1
- OPTIONS 5V 3A Type C power supply x1
- Screwdriver x1
CM4-NAS-Double-Deck
- Aluminum alloy case (2inch LCD included) x1
- CM4-NAS-Double-Deck x1
- CM4-FAN-3007 (fan screwpack and screwdriver included) x1
- Antenna x1
- IPEX to SMA cable ~20cm x1
- FPC 50PIN cable ~4cm x1
- Screws pack x1
- OPTIONS 5V 3A Type C power supply x1
- Screwdriver x1
