- Description
ATmega64 device in TQFP64 package and other pinout compatible devices of the sort
ATmega169 device in TQFP64 package and other pinout compatible devices of the sort
Unit: mm |
Part Number | Pitch | Pins | A x B | C x D | E | F | G x H |
IC51-0644-824-5 | 0.8 | 64 | 14 x 14 | 16 x 16 | 15.2 | - | 30 x 42.5 |
The M64+ ADP houses JTAG/ISP headers for connecting a programmer. The header pinouts are shown in the figures below.
Development resources:schematic, etc.
Wiki:
www.waveshare.com/wiki/M64+_ADP
Weight: 0.032 kg
